CHFIRE Shutoff Ball Valve

Shutoff Ball Valve Fire Nozzle

Features:

Flow Rate: 230LPM, 475LPM,950LPM;

Ball Valve Diameter: 35mm;

360° Swivel inlet, full time, even after tightening;

Coupling standard: Storz,NH,INST,GOST,Machino,etc.

DESCRIPTION

The ball shut-off valve swivels to release the flow of water. A grip directly attaches to a nozzle or tip for a greater degree of control. It can be used with almost any type of fire hose and can be easily adapted to the needs of different firefighting situations. Whether you are dealing with a small domestic fire or a large-scale industrial fire, this valve is an essential tool for any firefighter.

Model Material Inlet Size Outlet Size Flow Working Pressure
BV25-25 Hard Anodized Aluminum Alloy 1" / 25 mm 1" / 25 mm 230LPM 7bar
BV25-40 Hard Anodized Aluminum Alloy 1.5" / 40 mm 1" / 25 mm 475LPM,950LPM 7bar
BV25-50 Hard Anodized Aluminum Alloy 2" / 50mm 1" / 25 mm 475LPM,950LPM 7bar
BV25-65 Hard Anodized Aluminum Alloy 2.5" / 65 mm 1" / 25 mm 475LPM,950LPM 7bar
