Serial Number: CH22-21C
Model: PS40 or PS60
Brand: CHFIRE
Material: Stainless Steel 304/316
Flow: 40LPS or 60LPS
Flange Size: DN80 or DN100
Flange Standard: ANSI#150 or BS4504
| Model | PS40 | PS60 |
|---|---|---|
| Flow | 40LPS | 60LPS |
| Material | Stainless Steel 304 or 316 | Stainless Steel 304/316 |
| Distance (m) | ≥60 | ≥70 |
| Horizontal Rotation Angle (°) | 0 ~ 360 | 0 ~ 360 |
| Maximum Pitch Angle (°) | -70~+70 | -70~+70 |
| Flange Size | DN80 or DN100 | DN80 or DN100 |
| Flange Standard | ANSI#150 or BS4504 | ANSI#150 or BS4504 |
