Item Number: CH20-03
Body Material: Ductile iron as EN-GJS-450-10
Outlet Material: Copper alloy to BS 1400
Outlet Cap: 2 pcs black PE/rubber
Drain Valve: 1" Brass gate valve to BS5154
Drain Valve Cap: 1" Brass as BS CZ121
CHFIRE two way breeching inlet are typically installed outside the building to supply water to the fire pump, they are used to increase the pressure in the building's fire sprinkler systems.
| Model: | 2 Way Breeching Inlet |
| Inlet: | DN100 PN16 Flanged as EN 1092-2 |
| Outlet | 2x2.5"(DN65) British Instananeous |
| Test: | Factory hydro test 30 bar |
| Environment Temperature | 0°C to 38°C |
| Color | RAL3000 epoxy coating |
| Carton Size: | 34x23x20cm/1pc. |
| N.W./G.W.: | 14KG/15KG |
Stainless steel fire hose cabinet is a robust, corrosion-resistant enclosure designed for safe, organized storage of fire hoses, nozzles, valves, and related firefighting equipment. Built primarily from SUS304/316 stainless steel, it ensures long-term reliability in indoor/outdoor and harsh environments.
Fire extinguisher box has a reasonable internal structure for easy access and operation during emergencies. It is equipped with a clear safety logo, smooth opening mechanism, and stable mounting design, making installation and maintenance simple.
CHFIE Fire Extinguisher Cabinets for 10 lb. extinguishers can be used indoors or out to protect your fire extinguishers and make them noticeable and easy to access. Constructed of high-impact polystyrene and ultraviolet inhibitors, these surface mount FireTech extinguisher cabinets will not rust or fade, regardless of the weather or environment.
2.5" oblique fire hydrant landing valves are suitable for installation on wet risers in a building forfire fighting purposes with permanently charged water from a pressurized supply.
The pressure reducing valve utilizes the pilot valve for self-control, does not require other devices and energy, is easy to maintain, has high pressure control accuracy, is less affected by inlet pressure and flow, and has reliable pressure reduction and stabilization.
A fire hydrant box refers to a box used to store fire hydrants. It is used to extinguish fires when fires occur. It must be equipped with water hoses, water guns, etc. The installation methods include open-mounted, concealed, and semi-concealed.
Double-door fire fighting cabinets are mainly used to store push-type fire extinguishers, fire hoses, dry powder fire extinguishers and other equipment. Some models support layered storage of different types of fire fighting equipment.
The fire three-way water distributor is a device specially used in fire protection systems. Its main function is to reasonably distribute and control the water flow to ensure that water can be quickly and effectively delivered to various parts that need fire extinguishing when a fire occurs.
In firefighting, two way inlet dividing water breeching play a vital role. They are not only a key component in firefighting equipment, but also an important guarantee for firefighters to perform their tasks safely and efficiently. By deeply understanding the functions and usage of water distributors, we can better understand their indispensable role in firefighting.
