Pistol Grip Selectable Fire Nozzle for Firefighting Feature
Pattern identification.
Hard anodized aluminum, Laser engraved.
Simple to operate (1/4 turn from straight stream to fog).
Raised lug marks straight stream for limited visibility operations.
Easy to service & repair.
Compatible with quick attack foam tube.
Swivel inlet.
Low maintenance.
High flow range.
Excellent performance used worldwide.
CHFIRE 250GPM Pistol Grip Fire Nozzle is the most hot selling item, It has five adjustable flow, 360 - 475 - 570 - 760 LPM - 950 LPM. With the advantage of excellent performance and resonable price, highly admire from our plenty of customers.
| Model | 360 - 475 - 570 - 760 LPM - 950 LPM |
| Material of Body | Hard Anodized Aluminum Alloy |
| Material of Ball Valve | ABS(standard), Aluminum Alloy/stainless steel (optional) |
| Material of Valve Handle | ABS(standard), Aluminum Alloy(optional) |
| Material of Pistol Grip | ABS |
| Material of Bumper | Rubber |
| Working Pressure | 7bar |
| Max Working Pressure | 10bar |
| Jetting Range | 55meters @ 7 bar |
| Max Fog Angle | 120° |
| Flow Range | 360 - 475 - 570 - 760 LPM - 950 LPM - Flush(95-120-150-200-250GPM) |
| Inlet | 2.5inch, available for Storz,NH,INST,Machino |
125GPM Pistol Grip Fire Nozzle is designed for use with low pressure mainline hoses providing exceptional performance and long-term value.
60LPM Selectable Flow Fire Hose Nozzle is suitable for Wildland Forestry and mining industries, It has 3 flow rates to choose from 60-130-235LPM.
235 LPM Selectable Flow Fire Hose Nozzle is suitable for Wildland Forestry and mining industries, It has 3 flow rates to choose from 60-130-235LPM.
High pressure anodized aluminum 1inch, 1 1/2 inch, 2inch, 2 1/2inch NH pistol grip ball shut-off valve is lightweight and durable. Features a cast aluminum bale and durable polymer pistol grip that is easily removed. Pistol grip allows for stable and comfortable use. Valve has polymer ball and seating for reduced friction when opening and closing valve under pressure.May be used with any NH or NST threaded nozzle.
