Serial Number: CH26-05
Model: QLD6.0/4III-D
Flow Rate: 50-100-150-230LPM(13-25-40-60GPM);
Water Spray Angle: 180°;
Working Pressure: 7bar;
Max Working Pressure: 16bar
Max Flow Range: 25M
Coupling standard: Storz,NH,NPT,INST,GOST,Machino,etc.
CHFIRE FIREFIGHTING PISTOL GRIP NOZZLE FIRE HOSE NOZZLE FROM CHIAN MANUFACTURER
The multifunctional water gun is a commonly used firefighting equipment in the firefighting field, with the core function of adjustable spraying form. This equipment can realize the rapid switching of various water flow forms such as direct current jet and mist jet through mechanical adjustment device, and can improve the adaptability of fire scene when used in combination. Its small reaction force makes single-person operation more convenient, and it also has the additional function of straightening out the twisted state of the water hose. In actual firefighting, firefighters can flexibly adjust the spraying mode according to the specific conditions such as the type of combustibles and the intensity of combustion in the fire scene, taking into account the needs of long-distance precision spraying and large-area coverage and cooling.
| Model | QLD6.0/4III-D |
| Material of Body | Hard Anodized Aluminum Alloy |
| Material of Ball Valve | ABS(standard), Aluminum Alloy/stainless steel (optional) |
| Material of Valve Handle | ABS(standard), Aluminum Alloy(optional) |
| Material of Pistol Grip | ABS |
| Material of Bumper | Rubber |
| Working Pressure | 7bar |
| Max Working Pressure | 16bar |
| Jetting Range | 25meters @ 7 bar |
| Max Fog Angle | 120° |
| Flow Range | 50 - 100 - 150 - 230LPM- Flush(13-25-40-60GPM) |
| Inlet | 3/4", 1inch, 1.5", available for Storz,NH,INST,Machino |
